1 The socket plug of the sink of the inkjet printer manufacturer cannot be touched by hand to prevent oxidation.

2 During installation, the sink sockets must be aligned and cannot be inserted hard. If the pinhole is damaged or not properly inserted, the sink will not work normally.

3 Ink, rinsing liquid, etc. cannot be fed into the sink socket. The contaminated socket needs to be rinsed with alcohol.

4 When using the sink of inkjet printer manufacturers, they must maintain a good heat dissipation environment, otherwise the sink circuit will be easily damaged.

5 Static electricity affects the water sink circuit part very lightly. When operating the water sink or touching the water sink plugboard, the operating personnel must eliminate the static electricity factor.

6 If the water sink is disconnected during the coding process, stop the coding, expand and rinse the water sink. If the water sink is slightly blocked, solvent is needed to rinse the water sink, and then the ink is printed out.

7 After the printer manufacturer finishes coding, cover the sink protective cover on the sink and maintain this state for the equipment overnight.

8 Inkjet printers using quick-drying inks will encounter trouble with A6Km. The fourth major reason for A6Km is that after the ink solvent evaporates, ink particles solidify on the surface of the combustion chamber, causing nozzle holes to be blocked. The second reason is that there are impurities in the ink, or it reacts with a certain solution to form foreign matter, which is blocked inside the combustion chamber. The way to prevent this is to use a filter device, so that impurities cannot enter the ink cartridge, and often wash the sink.

9 The combustion chamber membrane on the surface of the water tank is made of polyimide film. Be careful when storing, disassembling, rinsing and boiling in the water tank. If you are scratched by hard objects, it will cause radiation in the combustion chamber and affect the quality of code coding.

10 The flushing sink uses a flushing solution dedicated for ink.

11 The blockage of the sink is generally the result of long-term accumulation, and users must always maintain the smoothness of the sink when using it.

12 The sink that is being used should be unfolded and rinsed thoroughly regularly. When it is not used for a long time, the sink can be removed and boiled for a long time.
